Hard Drive Overview

Capacity

512GB

Interface The interconnections that allow a device, a program, or a person to interact. Hardware interfaces are the cables that connect the device to its power source and to other devices. Software interfaces allow the program to communicate with other programs (such as the operating system), and user interfaces allow the user to communicate with the program (e.g., via mouse, menu commands, icons, voice commands, etc.).

PCIe SSD

Form Factor

M.2 2280

Dimensions

22 ± 0.15 mm x 80 ± 0.15 mm x 2.38 mm

Weight

7.2 ± 0.5 g

Operating Temperature

32 °F to 158 °F (0 °C to 70 °C)

Storage Devices used to store massive amounts of information so that it can be readily retrieved. Devices include RAIDs, CD-ROMs, DVDs Temperature

-67 °F to 185 °F (-55 °C to 85 °C)

Vibration Operating

5.0 gRMS, 10–2000 Hz, 3 axes

Vibration non-operating

4.9 gRMS, 7–800 Hz, 3 axes

MTBF

1.75M hours

Total Bytes Written (TBW)

160

PCMark

180K

Sequential Read MB/s (Q=32, T=1)

2,050

Sequential Write MB/s (Q=32, T=1)

800

Random Read 4 KB IOPS (Q=32, T=4)

170 K

Random Write 4KB IOPS (Q=32, T=4)

134 K
